Mono Input Channel Input electronically balanced, discrete input configuration Frequency response 15Hz to 25kHz, +/-3dB Distortion(THD&N) 0.05% at +4dBu, 1kHz Gain range 0dB to 40dB Equivalent Input Level -120dBu typical (XLR balanced, max gain) Stereo input channels Line input Balanced Frequency response 15Hz to 25kHz, +/-3dB Distortion(THD&N) 0.05% at +4dBu, 1kHz USB Section Windows2000/XP, Vista, Windows 7 and Mac OS X compliant USB 2.0 full speed compliant 16Bit 48kHz ADC/DAC USB input and output Impedances Microphone input 1.2Kohm Line input 33Kohm Tape input 22Kohm Main output 680ohm Monitor output 100ohm Tape output 1Kohm Equalization Hi shelving +/-15dB @12kHz Low shelving +/-15dB @80Hz Maximum levels Mic in +4dBu(XLR input), +14dBu(1/4¡±) Line in +18dBu Tape in +18dBu MAIN outputs 5.8Vmax MONITOR/PHONES 5Vmax Power supply USB bus powered 5Vdc External adapter 5Vdc Built in Li-ion-Battery 3.7V Power consumption 0.45 Watt typical 0.8Watt with full headphone output Li-ion Battery Recharge time Less than 3 hours Operation time More than 4 hours Dimension£¨£×£ø£Ä£ø£È£© 98mm £ø136mm £ø34mm Net weight 480g (1.1 lbs)
|
