Mono Input Channel Input electronically balanced, discrete input configuration Frequency response 15Hz to 25kHz, +/-3dB Distortion(THD&N) 0.05% at +4dBu, 1kHz Gain range 0dB to 50dB Equivalent Input Level -118dBu typical (XLR balanced, max gain) Stereo input channels Line input Balanced/ Unbalanced Frequency response 15Hz to 25kHz, +/-3dB Distortion(THD&N) 0.05% at +4dBu, 1kHz USB Section Windows98SE/ME/2000/XP, Vista, Windows 7 and Mac OS X compliant USB 2.0 full speed compliant 16Bit 48kHz ADC/DAC USB input and output Impedances Microphone input 2mV/2.2k Ohm (XLR), 10mV/150k Ohm (Inst-HiZ) CH3/4 Line input 360mV/22Kohm CH5/6 Line input 600mV/22Kohm Tape input 100mV/22Kohm Main output <1k Ohm (balanced 1/4¡±), <500 Ohms (unbalanced 1/4¡±) Monitor/Phones output 100ohm Tape output 1Kohm Equalization Hi shelving +/-15dB @12kHz Low shelving +/-15dB @80Hz Output levels MAIN OUT/TAPE OUT: 1.1V(at indication 0dbB) ,6.5V max MONITOR/PHONES: 6.5Vmax Phantom power Output: 48V ¡À 3V (Switchable) Power supply USA/Canada 120V ~60Hz; U.K/Australia 240V ~50Hz; Europe 230V ~50Hz; China/Korea 220V ~50Hz; Japan 100V ~60Hz Dimension£¨£×£ø£Ä£ø£È£©182.5mm £ø185mm £ø39mm
|
